FAG 61805-2RSR-HLC Image 4
Visual product photo and picture of the product.
Price: 11.71 $
Specifications
Weight and Dimensions
| Inner (d) MM |
25 |
| Outer (D) MM |
37 |
| Width (B) MM |
7 |
| Inner (d) Inch |
0.9843 |
| Outer (D) Inch |
1.4567 |
| Width (B) Inch |
0.2756 |
| Weight (kg) |
0.022 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
2RS - Rubber Seal on Two Sides |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
7 |
| Radial Static Load Rating C0r (N) |
2940 |
| Radial Dynamic Load Rating Cr (N) |
4300 |
| Basic static load rating, radial (C 0r) |
"2940.0000" |
| Limiting speed (n G) |
9500 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 618..-2RSR, single row, cf. DIN 625-1 |
Suffix description
| 2RSR |
Rubber Seals At Each Side Of The Bearing |
| HLC |
Factory Location Code, No Additional Meaning, Can Be Used As Standard |
