FAG 61804-2Z-L178-HLC Image 2
Visual product photo and picture of the product.
Price: 14.04 $
Specifications
Weight and Dimensions
| Inner (d) MM |
20 |
| Outer (D) MM |
32 |
| Width (B) MM |
7 |
| Inner (d) Inch |
0.7874 |
| Outer (D) Inch |
1.2598 |
| Width (B) Inch |
0.2756 |
| Weight (kg) |
0.018 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
ZZ/2Z - Steel Seal on Two Sides |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
7 |
| Radial Static Load Rating C0r (N) |
2460 |
| Radial Dynamic Load Rating Cr (N) |
4020 |
| Basic static load rating, radial (C 0r) |
"2460.0000" |
| Limiting speed (n G) |
28500 |
| Reference speed (n u03d1r) |
17200 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearings 618..-2Z, main dimensions to DIN 625-1, gap seals on both sides |
Suffix description
| 2Z |
Non-Contact Sealing Shield On Both Sides (Sheet Metal Gap Seal) |
| L178 |
High Speed Grease, Low And High Temp. -50°C / 120°C. Longtime Limit Temperature 75°C |
| HLC |
Factory Location Code, No Additional Meaning, Can Be Used As Standard |
