FAG 6092-M-C3 Image 3
Visual product photo and picture of the product.
Price: 0.00 $
Specifications
Weight and Dimensions
| Inner (d) MM |
460 |
| Outer (D) MM |
680 |
| Width (B) MM |
100 |
| Inner (d) Inch |
18.1102 |
| Outer (D) Inch |
26.7717 |
| Width (B) Inch |
3.937 |
| Weight (kg) |
120 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
100 |
| Radial Static Load Rating C0r (N) |
1070000 |
| Radial Dynamic Load Rating Cr (N) |
590000 |
| Basic static load rating, radial (C 0r) |
"1070000.0000" |
| Limiting speed (n G) |
1550 |
| Reference speed (n u03d1r) |
1200 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 60..-M, single row, cf. DIN 625-1 |
Suffix description
| M |
Solid Brass Cage, Ball-Guided |
| C3 |
Internal Clearance Larger Than Normal |
