FAG 6024-Z Image 3
Visual product photo and picture of the product.
Price: 123.22 $
Specifications
Weight and Dimensions
| Inner (d) MM |
120 |
| Outer (D) MM |
180 |
| Width (B) MM |
28 |
| Inner (d) Inch |
4.7244 |
| Outer (D) Inch |
7.0866 |
| Width (B) Inch |
1.1024 |
| Weight (kg) |
2.11 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
Z - Steel Seal on One Side |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
28 |
| Radial Static Load Rating C0r (N) |
77000 |
| Radial Dynamic Load Rating Cr (N) |
88000 |
| Basic static load rating, radial (C 0r) |
"77000.0000" |
| Limiting speed (n G) |
5000 |
| Reference speed (n u03d1r) |
4450 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 60..-Z, single row, cf. DIN 625-1 |
Suffix description
| Z |
Shield Of Pressed Sheet Steel On One Side Of The Bearing |
