FAG 6020-M-C4 Image 3
Visual product photo and picture of the product.
Price: 179.59 $
Specifications
Weight and Dimensions
| Inner (d) MM |
100 |
| Outer (D) MM |
150 |
| Width (B) MM |
24 |
| Inner (d) Inch |
3.937 |
| Outer (D) Inch |
5.9055 |
| Width (B) Inch |
0.9449 |
| Weight (kg) |
1.56 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C4 Internal Play (Higher than C3) |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
24 |
| Radial Static Load Rating C0r (N) |
54000 |
| Radial Dynamic Load Rating Cr (N) |
64000 |
| Basic static load rating, radial (C 0r) |
"54000.0000" |
| Limiting speed (n G) |
7900 |
| Reference speed (n u03d1r) |
5100 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 60..-M, single row, cf. DIN 625-1 |
Suffix description
| M |
Solid Brass Cage, Ball-Guided |
| C4 |
Bearing Internal Clearance Greater Than C3 |
