FAG 6005-C-2Z-L207-C3>V Image 3
Visual product photo and picture of the product.
Price: 5.95 $
Specifications
Weight and Dimensions
| Inner (d) MM |
25 |
| Outer (D) MM |
47 |
| Width (B) MM |
12 |
| Inner (d) Inch |
0.9843 |
| Outer (D) Inch |
1.8504 |
| Width (B) Inch |
0.4724 |
| Weight (kg) |
0.086 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
ZZ/2Z - Steel Seal on Two Sides |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
2 - High Temperature Grease |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
12 |
| Basic static load rating, radial (C 0r) |
6500 |
| Limiting speed (n G) |
20200 |
| Reference speed (n u03d1r) |
16400 |
Suffix description
| C |
Deep Groove Ball Bearings Of Generation C, Modified Internal Construction |
| 2Z |
Gap Seals On Both Sides |
| L207 |
Grease Filling With Arcanol L207 (High Temperature Grease) |
| C3 |
Internal Clearance Larger Than Normal |
| >V |
100% Identical Regardless Of Production Location |
