FAG 3308-DA-MA
Price: 172.96 $
Specifications
| Brand | FAG |
| Item Number | 3308-DA-MA FAG |
| Manufacturer Part Number | 0190023000000 |
| EAN | 4012801010450 |
| Category | Angular Contact Ball Bearing Double Row |
| Inner (d) MM | 40 |
| Outer (D) MM | 90 |
| Width (B) MM | 36,5 |
| Inner (d) Inch | 1.5748 |
| Outer (D) Inch | 3.5433 |
| Width (B) Inch | 1.437 |
| Weight (kg) | 1.145 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | MA - Brass Cage, Centered on Outer Ring |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Split inner ring |
| Width (b) mm | 36,5 |
| Radial Static Load Rating C0r (N) | 52000 |
| Radial Dynamic Load Rating Cr (N) | 62000 |
| Basic static load rating, radial (C 0r) | "52000.0000" |
| Limiting speed (n G) | 10700 |
| Reference speed (n u03d1r) | 6000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearing 33..-DA-MA, double row, 2 inner rings |
| DA | Ball Bearing Double Row With Split Inner Ring |
| MA | Machined Brass Cage, Outer Ring Guided |
