FAG 3308-BD-XL

FAG 3308-BD-XL
FAG 3308-BD-XL rulman resim 1
FAG 3308-BD-XL rulman resim 2
FAG 3308-BD-XL rulman resim 3
FAG 3308-BD-XL rulman resim 4
Price: 79.27 $
Specifications
Brand FAG
Item Number 3308-BD-XL FAG
Manufacturer Part Number 0713244530000
Also known as 3308-BD
EAN 4012802671797
Category Angular Contact Ball Bearing Double Row
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 90
Width (B) MM 36,5
Inner (d) Inch 1.5748
Outer (D) Inch 3.5433
Width (B) Inch 1.437
Weight (kg) 0.965 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Standard
Data from Schaeffler (medias)
Width (b) mm 36,5
Radial Static Load Rating C0r (N) 48500
Radial Dynamic Load Rating Cr (N) 67000
Basic static load rating, radial (C 0r) "48500.0000"
Limiting speed (n G) 8000
Reference speed (n u03d1r) 7000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 33..-BD, main dimensions to DIN 628-3, double row, contact angle a = 30°
Suffix description
BD Modified Internal Construction, Contact Angle u03b1=30°, Without Filling Slot
XL X-Life
