FAG 3307-DA-MA Image 4
Visual product photo and picture of the product.
Price: 154.70 $
Specifications
Weight and Dimensions
| Inner (d) MM |
35 |
| Outer (D) MM |
80 |
| Width (B) MM |
34,9 |
| Inner (d) Inch |
1.378 |
| Outer (D) Inch |
3.1496 |
| Width (B) Inch |
1.374 |
| Weight (kg) |
0.733 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Split inner ring |
Data from Schaeffler (medias)
| Width (b) mm |
34,9 |
| Radial Static Load Rating C0r (N) |
41000 |
| Radial Dynamic Load Rating Cr (N) |
50000 |
| Basic static load rating, radial (C 0r) |
"41000.0000" |
| Limiting speed (n G) |
12400 |
| Reference speed (n u03d1r) |
7100 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearing 33..-DA-MA, double row, 2 inner rings |
Suffix description
| DA |
Ball Bearing Double Row With Split Inner Ring |
| MA |
Machined Brass Cage, Outer Ring Guided |
