FAG 3305-BD-XL Image 2
Visual product photo and picture of the product.
Price: 50.98 $
Specifications
Weight and Dimensions
| Inner (d) MM |
25 |
| Outer (D) MM |
62 |
| Width (B) MM |
25,4 |
| Inner (d) Inch |
0.9843 |
| Outer (D) Inch |
2.4409 |
| Width (B) Inch |
1 |
| Weight (kg) |
0.344 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Standard |
Data from Schaeffler (medias)
| Width (b) mm |
25,4 |
| Radial Static Load Rating C0r (N) |
21000 |
| Radial Dynamic Load Rating Cr (N) |
31500 |
| Basic static load rating, radial (C 0r) |
"21000.0000" |
| Limiting speed (n G) |
12400 |
| Reference speed (n u03d1r) |
9400 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearings 33..-BD, main dimensions to DIN 628-3, double row, contact angle a = 30° |
Suffix description
| BD |
Modified Internal Construction, Contact Angle u03b1=30°, Without Filling Slot |
| XL |
X-Life |
