FAG 3304-BD-XL-2Z-TVH-C3 Image 3
Visual product photo and picture of the product.
Price: 40.39 $
Specifications
Weight and Dimensions
| Inner (d) MM |
20 |
| Outer (D) MM |
52 |
| Width (B) MM |
22,2 |
| Inner (d) Inch |
0.7874 |
| Outer (D) Inch |
2.0472 |
| Width (B) Inch |
0.874 |
| Weight (kg) |
0.2256 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
ZZ/2Z - Steel Seal on Two Sides |
| Cage Type |
P - Plastic Molded Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Standard |
Data from Schaeffler (medias)
| Width (b) mm |
22,2 |
| Radial Static Load Rating C0r (N) |
15900 |
| Radial Dynamic Load Rating Cr (N) |
24600 |
| Limiting speed (n G) |
11000 |
| Reference speed (n u03d1r) |
10400 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearing 33..-BD-XL-2Z-TVH, double row, 1 inner ring |
Suffix description
| BD |
Modified Internal Construction, Contact Angle u03b1=30°, Without Filling Slot |
| XL |
X-Life |
| 2Z |
Shields At Both Sides Of The Bearing |
| TVH |
Moulded Polyamide Cage Snap-Type, Rolling Element Riding |
| C3 |
Internal Clearance Larger Than Normal |
