FAG 3221-M Image 2
Visual product photo and picture of the product.
Price: 718.87 $
Specifications
Weight and Dimensions
| Inner (d) MM |
105 |
| Outer (D) MM |
190 |
| Width (B) MM |
65,1 |
| Inner (d) Inch |
4.1339 |
| Outer (D) Inch |
7.4803 |
| Width (B) Inch |
2.563 |
| Weight (kg) |
7.51 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Standard |
Data from Schaeffler (medias)
| Width (b) mm |
65,1 |
| Radial Static Load Rating C0r (N) |
270000 |
| Radial Dynamic Load Rating Cr (N) |
215000 |
| Basic static load rating, radial (C 0r) |
"270000.0000" |
| Limiting speed (n G) |
4600 |
| Reference speed (n u03d1r) |
3850 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearing 32..-M, double row, 1 inner ring |
Suffix description
| M |
Solid Brass Cage, Ball-Guided |
