FAG 3220 Image 4
Visual product photo and picture of the product.
Price: 406.70 $
Specifications
Weight and Dimensions
| Inner (d) MM |
100 |
| Outer (D) MM |
180 |
| Width (B) MM |
60,3 |
| Inner (d) Inch |
3.937 |
| Outer (D) Inch |
7.0866 |
| Width (B) Inch |
2.374 |
| Weight (kg) |
5.975 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Standard |
Data from Schaeffler (medias)
| Width (b) mm |
60,3 |
| Radial Static Load Rating C0r (N) |
235000 |
| Radial Dynamic Load Rating Cr (N) |
186000 |
| Basic static load rating, radial (C 0r) |
"235000.0000" |
| Limiting speed (n G) |
3750 |
| Reference speed (n u03d1r) |
4050 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearings 32, main dimensions to DIN 628-3, double row, with filling slots, contact angle a = 35° |
