FAG 3218-M Image 2
Visual product photo and picture of the product.
Price: 311.44 $
Specifications
Weight and Dimensions
| Inner (d) MM |
90 |
| Outer (D) MM |
160 |
| Width (B) MM |
52,4 |
| Inner (d) Inch |
3.5433 |
| Outer (D) Inch |
6.2992 |
| Width (B) Inch |
2.063 |
| Weight (kg) |
4.19 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Standard |
Data from Schaeffler (medias)
| Width (b) mm |
52,4 |
| Radial Static Load Rating C0r (N) |
172000 |
| Radial Dynamic Load Rating Cr (N) |
143000 |
| Basic static load rating, radial (C 0r) |
"172000.0000" |
| Limiting speed (n G) |
5600 |
| Reference speed (n u03d1r) |
4550 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearing 32..-M, double row, 1 inner ring |
Suffix description
| M |
Solid Brass Cage, Ball-Guided |
