FAG 30220-A-DF-A220-270 Image 2
Visual product photo and picture of the product.
Price: 438.96 $
Specifications
Weight and Dimensions
| Inner (d) MM |
100 |
| Outer (D) MM |
180 |
| Width (B) MM |
74 |
| Inner (d) Inch |
3.937 |
| Outer (D) Inch |
7.0866 |
| Width (B) Inch |
2.9134 |
| Weight (kg) |
7.82 kg
|
Product Properties
| Tapered Roller Pair Internal Play |
220-270µm |
Data from Schaeffler (medias)
| Inner ring total width (2B) mm |
68 |
| Radial Static Load Rating C0r (N) |
650000 |
| Radial Dynamic Load Rating Cr (N) |
430000 |
| Basic static load rating, radial (C 0r) |
"650000.0000" |
| Limiting speed (n G) |
4000 |
| Outer ring total width (2T) mm |
74 |
| Thermal speed rating (n u03d1r) |
2650 |
| ECLASS number |
23-05-09-10 |
| ECLASS2 number |
23-05-09-10 |
| Medias description |
Tapered roller bearing set 302..-A-DF, X-arrangement |
Suffix description
| A |
Internal Design Modification |
| DF |
Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A220-270 |
Axial Clearance In µm |
