FAG 24192-BEA-XL-K30-MB1 Image 3
Visual product photo and picture of the product.
Price: 0.00 $
Specifications
Weight and Dimensions
| Inner (d) MM |
460 |
| Outer (D) MM |
760 |
| Width (B) MM |
300 |
| Inner (d) Inch |
18.1102 |
| Outer (D) Inch |
29.9213 |
| Width (B) Inch |
11.811 |
| Weight (kg) |
550 kg
|
Product Properties
| Bore |
K3 u2013 1:30 Tapered Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
300 |
| Radial Static Load Rating C0r (N) |
14500000 |
| Radial Dynamic Load Rating Cr (N) |
8500000 |
| Basic static load rating, radial (C 0r) |
"14500000.0000" |
| Limiting speed (n G) |
660 |
| Reference speed (n u03d1r) |
241 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearings 241..-BEA-K30, main dimensions to DIN 635-2, with tapered bore, taper 1:30 |
Suffix description
| BE |
Maximum Capacity Design |
| A |
Modified Internal Construction |
| XL |
X-Life |
| K30 |
Tapered Bore, Taper 1:30 |
| MB1 |
Single-Piece Solid Brass Cage, Guided On Central Rib |
