FAG 24156-BE-XL-C3 Image 2
Visual product photo and picture of the product.
Price: 4,504.00 $
Specifications
Weight and Dimensions
| Inner (d) MM |
280 |
| Outer (D) MM |
460 |
| Width (B) MM |
180 |
| Inner (d) Inch |
11.0236 |
| Outer (D) Inch |
18.1102 |
| Width (B) Inch |
7.0866 |
| Weight (kg) |
118 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
S - Steel or Standard Cage |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
180 |
| Radial Static Load Rating C0r (N) |
5200000 |
| Radial Dynamic Load Rating Cr (N) |
3300000 |
| Basic static load rating, radial (C 0r) |
"5200000.0000" |
| Limiting speed (n G) |
1230 |
| Reference speed (n u03d1r) |
520 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearing 241..-BE-XL, symmetric with rib washer |
Suffix description
| BE |
Maximum Capacity Design |
| XL |
X-Life |
| C3 |
Internal Clearance Larger Than Normal |
