FAG 24128-BE-XL-K30-C3 Image 3
Visual product photo and picture of the product.
Price: 767.12 $
Specifications
Weight and Dimensions
| Inner (d) MM |
140 |
| Outer (D) MM |
225 |
| Width (B) MM |
85 |
| Inner (d) Inch |
5.5118 |
| Outer (D) Inch |
8.8583 |
| Width (B) Inch |
3.3465 |
| Weight (kg) |
11.8 kg
|
Product Properties
| Bore |
K3 u2013 1:30 Tapered Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
S - Steel or Standard Cage |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
85 |
| Radial Static Load Rating C0r (N) |
1190000 |
| Radial Dynamic Load Rating Cr (N) |
800000 |
| Basic static load rating, radial (C 0r) |
"1190000.0000" |
| Limiting speed (n G) |
2650 |
| Reference speed (n u03d1r) |
1430 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearings 241..-BE-K30, main dimensions to DIN 635-2, with tapered bore, taper 1:30 |
Suffix description
| BE |
Maximum Capacity Design |
| XL |
X-Life |
| K30 |
Tapered Bore, Taper 1:30 |
| C3 |
Internal Clearance Larger Than Normal |
