FAG 24126-BE-XL-T52BW-C3 Image 5
Visual product photo and picture of the product.
Price: 682.09 $
Specifications
Weight and Dimensions
| Inner (d) MM |
130 |
| Outer (D) MM |
210 |
| Width (B) MM |
80 |
| Weight (kg) |
10.8 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
S - Steel or Standard Cage |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Higher Running Acc. ISO Cl.5 |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Radial Static Load Rating C0r (N) |
1050000 |
| Radial Dynamic Load Rating Cr (N) |
710000 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearing 241..-BE-XL, symmetric with rib washer |
Suffix description
| BE |
Maximum Capacity Design |
| XL |
X-Life |
| T52BW |
Heightened Running Accuracy To ISO Tolerance Class 5 |
| C3 |
Internal Clearance Larger Than Normal |
