FAG 24126-BE-XL-2VSR-H40-C4 Image 5
Visual product photo and picture of the product.
Price: 1,170.97 $
Specifications
Weight and Dimensions
| Inner (d) MM |
130 |
| Outer (D) MM |
210 |
| Width (B) MM |
80 |
| Inner (d) Inch |
5.1181 |
| Outer (D) Inch |
8.2677 |
| Width (B) Inch |
3.1496 |
| Weight (kg) |
10.7 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W - No Lubrication Groove or Holes |
| Seal |
2RS2 - Fluoro Rubber Seals / High Temperature |
| Cage Type |
S - Steel or Standard Cage |
| Radial Internal Play |
C4 Internal Play (Higher than C3) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
80 |
| Basic static load rating, radial (C 0r) |
1050000 |
| Limiting speed (n G) |
700 |
Suffix description
| BE |
Maximum Capacity Design |
| XL |
X-Life |
| 2VSR |
Sheet Steel Reinforced Rubbing Seals Of Fluoro Rubber (FPM) At Both Sides Of The Bearing. Grease Fill 70 To 100% With A Plyurea High Temperature Grease. Annular Groove And Three Lubricating Holes In The Outer Ring |
| H40 |
Bearings Without Lubricating Groove And Holes; H40 Replaces Z26, Completely Closed Outer Ring |
| C4 |
Bearing Internal Clearance Greater Than C3 |
