FAG 24024-BE-XL-2VSR-H40
Price: 752.88 $
Specifications
| Brand | FAG |
| Item Number | 24024-BE-XL-2VSR-H40 FAG |
| Manufacturer Part Number | 0790705400000 |
| Also known as |
24024-BE-2VSR-H40 |
| EAN | 4047643330831 |
| Category | Spherical Roller Bearing |
| Inner (d) MM | 120 |
| Outer (D) MM | 180 |
| Width (B) MM | 60 |
| Inner (d) Inch | 4.7244 |
| Outer (D) Inch | 7.0866 |
| Width (B) Inch | 2.3622 |
| Weight (kg) | 5.45 kg |
| Bore | C - Cylindrical Bore |
| Lubrication Enhancement | W - No Lubrication Groove or Holes |
| Seal | 2RS2 - Fluoro Rubber Seals / High Temperature |
| Cage Type | S - Steel or Standard Cage |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Width (b) mm | 60 |
| Radial Static Load Rating C0r (N) | 690000 |
| Radial Dynamic Load Rating Cr (N) | 450000 |
| Basic static load rating, radial (C 0r) | "690000.0000" |
| Limiting speed (n G) | 860 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearing 240..-BE-XL-2VSR-H40, symmetric with rib washer |
| BE | Maximum Capacity Design |
| XL | X-Life |
| 2VSR | Sheet Steel Reinforced Rubbing Seals Of Fluoro Rubber (FPM) At Both Sides Of The Bearing. Grease Fill 70 To 100% With A Plyurea High Temperature Grease. Annular Groove And Three Lubricating Holes In The Outer Ring |
| H40 | Bearings Without Lubricating Groove And Holes; H40 Replaces Z26, Completely Closed Outer Ring |
| C3 | Internal Clearance Larger Than Normal |
