FAG 24024-BE-XL-K30-C3
Price: 400.55 $
Specifications
| Brand | FAG |
| Item Number | 24024-BE-XL-K30-C3 FAG |
| Manufacturer Part Number | 0586030770030 |
| Also known as |
24024-BE-K30-C3 |
| EAN | 4012802314014 |
| Category | Spherical Roller Bearing |
| Inner (d) MM | 120 |
| Outer (D) MM | 180 |
| Width (B) MM | 60 |
| Inner (d) Inch | 4.7244 |
| Outer (D) Inch | 7.0866 |
| Width (B) Inch | 2.3622 |
| Weight (kg) | 5.209 kg |
| Bore | K3 u2013 1:30 Tapered Bore |
| Lubrication Enhancement | W33 - Lubrication Groove and 3 Holes |
| Seal | No Seal |
| Cage Type | S - Steel or Standard Cage |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Width (b) mm | 60 |
| Radial Static Load Rating C0r (N) | 690000 |
| Radial Dynamic Load Rating Cr (N) | 450000 |
| Basic static load rating, radial (C 0r) | "690000.0000" |
| Limiting speed (n G) | 3450 |
| Reference speed (n u03d1r) | 2360 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearings 240..-BE-K30, main dimensions to DIN 635-2, with tapered bore, taper 1:30 |
| BE | Maximum Capacity Design |
| XL | X-Life |
| K30 | Tapered Bore, Taper 1:30 |
| C3 | Internal Clearance Larger Than Normal |
