FAG 23940-S-MB-C3 Image 5
Visual product photo and picture of the product.
Price: 854.63 $
Specifications
Weight and Dimensions
| Inner (d) MM |
200 |
| Outer (D) MM |
280 |
| Width (B) MM |
60 |
| Inner (d) Inch |
7.874 |
| Outer (D) Inch |
11.0236 |
| Width (B) Inch |
2.3622 |
| Weight (kg) |
12.3 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
60 |
| Radial Static Load Rating C0r (N) |
1070000 |
| Radial Dynamic Load Rating Cr (N) |
550000 |
| Basic static load rating, radial (C 0r) |
"1070000.0000" |
| Limiting speed (n G) |
2800 |
| Reference speed (n u03d1r) |
1650 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearings 239, main dimensions to DIN 635-2 |
Suffix description
| S |
Lubrication Groove And Three Holes In Bearing Outer Ring |
| MB |
Solid Brass Cage, Guidance On Inner Ring |
| C3 |
Internal Clearance Larger Than Normal |
