FAG 239/500-MB-T52BW-C3 Image 3
Visual product photo and picture of the product.
Price: 0.00 $
Specifications
Weight and Dimensions
| Inner (d) MM |
500 |
| Outer (D) MM |
670 |
| Width (B) MM |
128 |
| Inner (d) Inch |
19.685 |
| Outer (D) Inch |
26.378 |
| Width (B) Inch |
5.0394 |
| Weight (kg) |
133 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Higher Running Acc. ISO Cl.5 |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
128 |
| Radial Static Load Rating C0r (N) |
6300000 |
| Radial Dynamic Load Rating Cr (N) |
2600000 |
| Basic static load rating, radial (C 0r) |
"6300000.0000" |
| Limiting speed (n G) |
990 |
| Reference speed (n u03d1r) |
540 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearing 239..-MB, symmetric 3 ribs |
Suffix description
| MB |
Solid Brass Cage, Guidance On Inner Ring |
| T52BW |
Heightened Running Accuracy To ISO Tolerance Class 5 |
| C3 |
Internal Clearance Larger Than Normal |
