FAG 23328-AS-MA-T41A-C3 Image 3
Visual product photo and picture of the product.
Price: 2,407.35 $
Specifications
Weight and Dimensions
| Inner (d) MM |
140 |
| Outer (D) MM |
300 |
| Width (B) MM |
118 |
| Inner (d) Inch |
5.5118 |
| Outer (D) Inch |
11.811 |
| Width (B) Inch |
4.6457 |
| Weight (kg) |
40.7 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
118 |
| Radial Static Load Rating C0r (N) |
1800000 |
| Radial Dynamic Load Rating Cr (N) |
1270000 |
| Basic static load rating, radial (C 0r) |
"1800000.0000" |
| Limiting speed (n G) |
2000 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearings 233..-A-MA-T41A, For oscillating load with restricted diameter tolerances |
Suffix description
| A |
Modified Internal Construction |
| S |
Lubrication Groove And Three Holes In Bearing Outer Ring |
| MA |
Machined Brass Cage, Outer Ring Guided |
| T41A |
Spherical Roller Bearings For Vibrating Screens (C4 Clearance), Old Designation is C4.F80 |
| C3 |
Internal Clearance Larger Than Normal |
