FAG 23124-E1A-XL-K-M-C4 Image 3
Visual product photo and picture of the product.
Price: 505.64 $
Specifications
Weight and Dimensions
| Inner (d) MM |
120 |
| Outer (D) MM |
200 |
| Width (B) MM |
62 |
| Inner (d) Inch |
4.7244 |
| Outer (D) Inch |
7.874 |
| Width (B) Inch |
2.4409 |
| Weight (kg) |
7.53 kg
|
Product Properties
| Bore |
K - 1:12 Tapered Bore (Standard for Most Types) |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Radial Internal Play |
C4 Internal Play (Higher than C3) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
62 |
| Radial Static Load Rating C0r (N) |
800000 |
| Radial Dynamic Load Rating Cr (N) |
630000 |
| Basic static load rating, radial (C 0r) |
"800000.0000" |
| Limiting speed (n G) |
3400 |
| Reference speed (n u03d1r) |
2290 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearings 231..-E1A-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12 |
Suffix description
| E1 |
Increased Capacity Design |
| A |
Modified Internal Construction |
| XL |
X-Life |
| K |
Tapered Bore, Taper 1:12 |
| M |
Solid Brass Cage, Guided By Rollers |
| C4 |
Bearing Internal Clearance Greater Than C3 |
