FAG 23124-E1-K-TVPB Image 6

Visual product photo and picture of the product.

FAG 23124-E1-K-TVPB bearing image 6
FAG 23124-E1-K-TVPB bearing image 1
FAG 23124-E1-K-TVPB bearing image 2
FAG 23124-E1-K-TVPB bearing image 3
FAG 23124-E1-K-TVPB bearing image 4
FAG 23124-E1-K-TVPB bearing image 5
FAG 23124-E1-K-TVPB bearing image 6
FAG 23124-E1-K-TVPB bearing image 7
FAG 23124-E1-K-TVPB bearing image 8
Price: 355.95 $
Specifications
Brand FAG
Item Number 23124-E1-K-TVPB FAG
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 120
Outer (D) MM 200
Width (B) MM 62
Inner (d) Inch 4.7244
Outer (D) Inch 7.874
Width (B) Inch 2.4409
Weight (kg) 7.3 kg
Product Properties
Bore K - 1:12 Tapered Bore (Standard for Most Types)
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type P - Plastic Molded Cage
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Suffix description
E1 Increased Capacity Design
K Tapered Bore, Taper 1:12
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
