FAG 23120-E1A-XL-M-C3
Price: 246.36 $
Specifications
| Brand | FAG |
| Item Number | 23120-E1A-XL-M-C3 FAG |
| Manufacturer Part Number | 0190302820030 |
| Also known as |
23120-E1A-M-C3 |
| EAN | 4026677809599 |
| Category | Spherical Roller Bearing |
| Inner (d) MM | 100 |
| Outer (D) MM | 165 |
| Width (B) MM | 52 |
| Inner (d) Inch | 3.937 |
| Outer (D) Inch | 6.4961 |
| Width (B) Inch | 2.0472 |
| Weight (kg) | 4.37 kg |
| Bore | C - Cylindrical Bore |
| Lubrication Enhancement | W33 - Lubrication Groove and 3 Holes |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Width (b) mm | 52 |
| Radial Static Load Rating C0r (N) | 570000 |
| Radial Dynamic Load Rating Cr (N) | 450000 |
| Basic static load rating, radial (C 0r) | "570000.0000" |
| Limiting speed (n G) | 4000 |
| Reference speed (n u03d1r) | 2750 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearings 231..-E1A, main dimensions to DIN 635-2 |
| E1 | Increased Capacity Design |
| A | Modified Internal Construction |
| XL | X-Life |
| M | Solid Brass Cage, Guided By Rollers |
| C3 | Internal Clearance Larger Than Normal |
