FAG 23120-E1-XL-K-TVPB
Price: 234.89 $
Specifications
| Brand | FAG |
| Item Number | 23120-E1-XL-K-TVPB FAG |
| Manufacturer Part Number | 0190065860000 |
| Also known as |
23120-E1-K-TVPB |
| EAN | 4026677809643 |
| Category | Spherical Roller Bearing |
| Inner (d) MM | 100 |
| Outer (D) MM | 165 |
| Width (B) MM | 52 |
| Inner (d) Inch | 3.937 |
| Outer (D) Inch | 6.4961 |
| Width (B) Inch | 2.0472 |
| Weight (kg) | 4.2 kg |
| Bore | K - 1:12 Tapered Bore (Standard for Most Types) |
| Lubrication Enhancement | W33 - Lubrication Groove and 3 Holes |
| Seal | No Seal |
| Cage Type | P - Plastic Molded Cage |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Width (b) mm | 52 |
| Radial Static Load Rating C0r (N) | 570000 |
| Radial Dynamic Load Rating Cr (N) | 450000 |
| Basic static load rating, radial (C 0r) | "570000.0000" |
| Limiting speed (n G) | 4000 |
| Reference speed (n u03d1r) | 2750 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearings 231..-E1-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12 |
| E1 | Increased Capacity Design |
| XL | X-Life |
| K | Tapered Bore, Taper 1:12 |
| TVPB | Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring |
