Price: 234.89 $
Specifications
Brand FAG
Item Number 23120-E1-K-TVPB-C3 FAG
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 100
Outer (D) MM 165
Width (B) MM 52
Inner (d) Inch 3.937
Outer (D) Inch 6.4961
Width (B) Inch 2.0472
Weight (kg) 4.2 kg
Product Properties
Bore K - 1:12 Tapered Bore (Standard for Most Types)
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type P - Plastic Molded Cage
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Suffix description
E1 Increased Capacity Design
K Tapered Bore, Taper 1:12
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
C3 Internal Clearance Larger Than Normal
