FAG 23064-BEA-XL-MB1 Image 2
Visual product photo and picture of the product.
Price: 3,334.80 $
Specifications
Weight and Dimensions
| Inner (d) MM |
320 |
| Outer (D) MM |
480 |
| Width (B) MM |
121 |
| Inner (d) Inch |
12.5984 |
| Outer (D) Inch |
18.8976 |
| Width (B) Inch |
4.7638 |
| Weight (kg) |
80.1 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
121 |
| Radial Static Load Rating C0r (N) |
3750000 |
| Radial Dynamic Load Rating Cr (N) |
2300000 |
| Basic static load rating, radial (C 0r) |
"3750000.0000" |
| Limiting speed (n G) |
1480 |
| Reference speed (n u03d1r) |
920 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearing 230..-BEA-XL-MB1, symmetric 2 outer ribs with rib washer |
Suffix description
| BE |
Maximum Capacity Design |
| A |
Modified Internal Construction |
| XL |
X-Life |
| MB1 |
Single-Piece Solid Brass Cage, Guided On Central Rib |
