FAG 230/560-BEA-XL-MB1 Image 2
Visual product photo and picture of the product.
Price: 0.00 $
Specifications
Weight and Dimensions
| Inner (d) MM |
560 |
| Outer (D) MM |
820 |
| Width (B) MM |
195 |
| Inner (d) Inch |
22.0472 |
| Outer (D) Inch |
32.2835 |
| Width (B) Inch |
7.6772 |
| Weight (kg) |
355 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
195 |
| Radial Static Load Rating C0r (N) |
11200000 |
| Radial Dynamic Load Rating Cr (N) |
6100000 |
| Basic static load rating, radial (C 0r) |
"11200000.0000" |
| Limiting speed (n G) |
760 |
| Reference speed (n u03d1r) |
440 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearing 230..-BEA-XL-MB1, symmetric 2 outer ribs with rib washer |
Suffix description
| BE |
Maximum Capacity Design |
| A |
Modified Internal Construction |
| XL |
X-Life |
| MB1 |
Single-Piece Solid Brass Cage, Guided On Central Rib |
