FAG 22338-BE-XL-C3 Image 3
Visual product photo and picture of the product.
Price: 2,677.62 $
Specifications
Weight and Dimensions
| Inner (d) MM |
190 |
| Outer (D) MM |
400 |
| Width (B) MM |
132 |
| Inner (d) Inch |
7.4803 |
| Outer (D) Inch |
15.748 |
| Width (B) Inch |
5.1969 |
| Weight (kg) |
78.4 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
S - Steel or Standard Cage |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
132 |
| Radial Static Load Rating C0r (N) |
2650000 |
| Radial Dynamic Load Rating Cr (N) |
2220000 |
| Limiting speed (n G) |
1940 |
| Reference speed (n u03d1r) |
1160 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearings 223..-E1, main dimensions to DIN 635-2 |
Suffix description
| BE |
Maximum Capacity Design |
| XL |
X-Life |
| C3 |
Internal Clearance Larger Than Normal |
