FAG 22320-E1A-XL-MA-T41A Image 8
Visual product photo and picture of the product.
Price: 645.52 $
Specifications
Weight and Dimensions
| Inner (d) MM |
100 |
| Outer (D) MM |
215 |
| Width (B) MM |
73 |
| Inner (d) Inch |
3.937 |
| Outer (D) Inch |
8.4646 |
| Width (B) Inch |
2.874 |
| Weight (kg) |
12.8 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| Radial Internal Play |
C4 Internal Play (Higher than C3) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
73 |
| Radial Static Load Rating C0r (N) |
920000 |
| Radial Dynamic Load Rating Cr (N) |
810000 |
| Basic static load rating, radial (C 0r) |
"920000.0000" |
| Limiting speed (n G) |
3300 |
| Reference speed (n u03d1r) |
2380 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearing 223..-E1A-XL-MA-T41A, symmetric 2 outer ribs |
Suffix description
| E1 |
Increased Capacity Design |
| A |
Modified Internal Construction |
| XL |
X-Life |
| MA |
Machined Brass Cage, Outer Ring Guided |
| T41A |
Spherical Roller Bearings For Vibrating Screens (C4 Clearance), Old Designation is C4.F80 |
