FAG 22320-E1-XL-T52BW-C3 Image 4
Visual product photo and picture of the product.
Price: 600.45 $
Specifications
Weight and Dimensions
| Inner (d) MM |
100 |
| Outer (D) MM |
215 |
| Width (B) MM |
73 |
| Inner (d) Inch |
3.937 |
| Outer (D) Inch |
8.4646 |
| Width (B) Inch |
2.874 |
| Weight (kg) |
12.1 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
S - Steel or Standard Cage |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Higher Running Acc. ISO Cl.5 |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
73 |
| Radial Static Load Rating C0r (N) |
920000 |
| Radial Dynamic Load Rating Cr (N) |
810000 |
| Limiting speed (n G) |
3300 |
| Reference speed (n u03d1r) |
2380 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearings 223..-E1, main dimensions to DIN 635-2 |
Suffix description
| E1 |
Increased Capacity Design |
| XL |
X-Life |
| T52BW |
Heightened Running Accuracy To ISO Tolerance Class 5 |
| C3 |
Internal Clearance Larger Than Normal |
