FAG 22312-E1-XL-TVPB-C3 Image 2
Visual product photo and picture of the product.
Price: 124.03 $
Specifications
Weight and Dimensions
| Inner (d) MM |
60 |
| Outer (D) MM |
130 |
| Width (B) MM |
46 |
| Inner (d) Inch |
2.3622 |
| Outer (D) Inch |
5.1181 |
| Width (B) Inch |
1.811 |
| Weight (kg) |
2.8 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
P - Plastic Molded Cage |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
Suffix description
| E1 |
Increased Capacity Design |
| XL |
X-Life |
| TVPB |
Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring |
| C3 |
Internal Clearance Larger Than Normal |
