FAG 22218-E1-XL-C2 Image 2
Visual product photo and picture of the product.
Price: 185.47 $
Specifications
Weight and Dimensions
| Inner (d) MM |
90 |
| Outer (D) MM |
160 |
| Width (B) MM |
40 |
| Inner (d) Inch |
3.5433 |
| Outer (D) Inch |
6.2992 |
| Width (B) Inch |
1.5748 |
| Weight (kg) |
3.18 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
No Seal |
| Cage Type |
S - Steel or Standard Cage |
| Radial Internal Play |
C2 Internal Play (Less than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
40 |
| Radial Static Load Rating C0r (N) |
375000 |
| Radial Dynamic Load Rating Cr (N) |
345000 |
| Basic static load rating, radial (C 0r) |
"375000.0000" |
| Limiting speed (n G) |
5200 |
| Reference speed (n u03d1r) |
3400 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearings 222..-E1, main dimensions to DIN 635-2 |
Suffix description
| E1 |
Increased Capacity Design |
| XL |
X-Life |
| C2 |
Bearing Internal Clearance Smaller Than Normal |
