FAG 22216-E1-XL-K-H40 Image 2
Visual product photo and picture of the product.
Price: 125.79 $
Specifications
Weight and Dimensions
| Inner (d) MM |
80 |
| Outer (D) MM |
140 |
| Width (B) MM |
33 |
| Inner (d) Inch |
3.1496 |
| Outer (D) Inch |
5.5118 |
| Width (B) Inch |
1.2992 |
| Weight (kg) |
1.96 kg
|
Product Properties
| Bore |
K - 1:12 Tapered Bore (Standard for Most Types) |
| Lubrication Enhancement |
W - No Lubrication Groove or Holes |
| Seal |
No Seal |
| Cage Type |
S - Steel or Standard Cage |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
33 |
| Radial Static Load Rating C0r (N) |
270000 |
| Radial Dynamic Load Rating Cr (N) |
250000 |
| Basic static load rating, radial (C 0r) |
"270000.0000" |
| Limiting speed (n G) |
6200 |
| Reference speed (n u03d1r) |
3550 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearing 222..-E1-XL-K-H40, symmetric with cage guidance ring |
Suffix description
| E1 |
Increased Capacity Design |
| XL |
X-Life |
| K |
Tapered Bore, Taper 1:12 |
| H40 |
Bearings Without Lubricating Groove And Holes; H40 Replaces Z26, Completely Closed Outer Ring |
