FAG 21310-E1-XL-TVPB

FAG 21310-E1-XL-TVPB
FAG 21310-E1-XL-TVPB rulman resim 1
FAG 21310-E1-XL-TVPB rulman resim 2
FAG 21310-E1-XL-TVPB rulman resim 3
FAG 21310-E1-XL-TVPB rulman resim 4
Price: 77.73 $
Specifications
Brand FAG
Item Number 21310-E1-XL-TVPB FAG
Manufacturer Part Number 0167023520000
Also known as 21310-E1-TVPB
EAN 4026677807397
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 110
Width (B) MM 27
Inner (d) Inch 1.9685
Outer (D) Inch 4.3307
Width (B) Inch 1.063
Weight (kg) 1.21 kg
Product Properties
Bore C - Cylindrical Bore
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type P - Plastic Molded Cage
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm 27
Radial Static Load Rating C0r (N) 130000
Radial Dynamic Load Rating Cr (N) 129000
Basic static load rating, radial (C 0r) "130000.0000"
Limiting speed (n G) 9000
Reference speed (n u03d1r) 5400
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 213..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
