FAG 21305-E1-XL-TVPB-C3

FAG 21305-E1-XL-TVPB-C3
FAG 21305-E1-XL-TVPB-C3 rulman resim 1
FAG 21305-E1-XL-TVPB-C3 rulman resim 2
FAG 21305-E1-XL-TVPB-C3 rulman resim 3
FAG 21305-E1-XL-TVPB-C3 rulman resim 4
FAG 21305-E1-XL-TVPB-C3 rulman resim 5
Price: 46.95 $
Specifications
Brand FAG
Item Number 21305-E1-XL-TVPB-C3 FAG
Manufacturer Part Number 0190001890030
Also known as 21305-E1-TVPB-C3
EAN 4026677808127
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 62
Width (B) MM 17
Inner (d) Inch 0.9843
Outer (D) Inch 2.4409
Width (B) Inch 0.6693
Weight (kg) 0.254 kg
Product Properties
Bore C - Cylindrical Bore
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type P - Plastic Molded Cage
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm 17
Radial Static Load Rating C0r (N) 43500
Radial Dynamic Load Rating Cr (N) 52000
Basic static load rating, radial (C 0r) "43500.0000"
Limiting speed (n G) 13900
Reference speed (n u03d1r) 8400
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 213..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
C3 Internal Clearance Larger Than Normal
