FAG 20226-K-MB-C3 Image 5
Visual product photo and picture of the product.
Price: 1,097.46 $
Specifications
Weight and Dimensions
| Inner (d) MM |
130 |
| Outer (D) MM |
230 |
| Width (B) MM |
40 |
| Inner (d) Inch |
5.1181 |
| Outer (D) Inch |
9.0551 |
| Width (B) Inch |
1.5748 |
| Weight (kg) |
7.3 kg
|
Product Properties
| Bore |
K - 1:12 Tapered Bore (Standard for Most Types) |
| Lubrication Enhancement |
W - No Lubrication Groove or Holes |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
40 |
| Radial Static Load Rating C0r (N) |
450000 |
| Radial Dynamic Load Rating Cr (N) |
330000 |
| Basic static load rating, radial (C 0r) |
"450000.0000" |
| Limiting speed (n G) |
3300 |
| ECLASS number |
23-05-09-12 |
| ECLASS2 number |
23-05-09-12 |
| Medias description |
Barrel roller bearing 202..-K-MB |
Suffix description
| K |
Tapered Bore, Taper 1:12 |
| MB |
Solid Brass Cage, Guidance On Inner Ring |
| C3 |
Internal Clearance Larger Than Normal |
