FAG 1319-K-M-C3 Image 3
Visual product photo and picture of the product.
Price: 454.12 $
Specifications
Weight and Dimensions
| Inner (d) MM |
95 |
| Outer (D) MM |
200 |
| Width (B) MM |
45 |
| Inner (d) Inch |
3.7402 |
| Outer (D) Inch |
7.874 |
| Width (B) Inch |
1.7717 |
| Weight (kg) |
6.9 kg
|
Product Properties
| Bore |
K - 1:12 Tapered Bore (Standard for Most Types) |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
45 |
| Radial Static Load Rating C0r (N) |
51000 |
| Radial Dynamic Load Rating Cr (N) |
134000 |
| Basic static load rating, radial (C 0r) |
"51000.0000" |
| Limiting speed (n G) |
5100 |
| Reference speed (n u03d1r) |
4050 |
| ECLASS number |
23-05-08-06 |
| ECLASS2 number |
23-05-08-06 |
| Medias description |
Self-aligning ball bearings 13..-K, main dimensions to DIN 630, with tapered bore, taper 1:12 |
Suffix description
| K |
Tapered Bore, Taper 1:12 |
| M |
Solid Brass Cage |
| C3 |
Internal Clearance Larger Than Normal |
