FAG 11209-TVH Image 5
Visual product photo and picture of the product.
Price: 62.46 $
Specifications
Weight and Dimensions
| Inner (d) MM |
45 |
| Outer (D) MM |
85 |
| Width (B) MM |
58 |
| Inner (d) Inch |
1.7717 |
| Outer (D) Inch |
3.3465 |
| Width (B) Inch |
2.2835 |
| Weight (kg) |
0.77 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
P - Plastic Molded Cage |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Radial Static Load Rating C0r (N) |
7300 |
| Width inner ring (B) mm |
58 |
| Width outer ring (B) mm |
19 |
| Radial Dynamic Load Rating Cr (N) |
22000 |
| Basic static load rating, radial (C 0r) |
"7300.0000" |
| Limiting speed (n G) |
9300 |
| Reference speed (n u03d1r) |
8200 |
| ECLASS number |
23-05-08-06 |
| ECLASS2 number |
23-05-08-06 |
| Medias description |
Self-aligning ball bearings 112, main dimensions to DIN 630, with extended inner ring |
Suffix description
| TVH |
Solid Cage Made From Glass Fibre Reinforced Polyamide 66 |
