SKF 23024CCK/C3W33
Price: 289.42 $
Specifications
| Brand | SKF |
| Item Number | 23024CCK/C3W33 SKF |
| EAN | 7316576654916 |
| Category | Spherical Roller Bearing |
| Inner (d) MM | 120 |
| Outer (D) MM | 180 |
| Width (B) MM | 46 |
| Inner (d) Inch | 4.7244 |
| Outer (D) Inch | 7.0866 |
| Width (B) Inch | 1.811 |
| Weight (kg) | 3.8 kg |
| Bore | K - 1:12 Tapered Bore (Standard for Most Types) |
| Lubrication Enhancement | W33 - Lubrication Groove and 3 Holes |
| Seal | No Seal |
| Cage Type | S - Steel or Standard Cage |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| CC | Two Window-Type Steel Cages, Flangeless Inner Ring And Guide Ring Centered On The Inner Ring |
| K | Tapered Bore, Taper 1:12 |
| C3 | Internal Clearance Larger Than Normal |
| W33 | Lubrication Groove And Three Holes In Bearing Outer Ring |
