NSK 7309BTDTDP5

Specifications

Brand	NSK
Item Number	7309BTDTDP5 NSK
Category	Angular Contact Ball Bearing Single Row

Weight and Dimensions

Inner (d) MM	45
Outer (D) MM	100
Width (B) MM	75
Inner (d) Inch	1.7717
Outer (D) Inch	3.937
Width (B) Inch	2.9528
Weight (kg)	2.694 kg

Product Properties

Seal	No Seal
Cage Type	TB - Hard Fiber Cage
Precision	P5 Precision (Higher than P6)
Contact Angle	40 degrees
Pairing	TU - Tripple Set, Universal, 3
Axial Internal Clearance / Preload	No Preload
Lubrication	Standard Lubrication

Suffix description

B	40° Contact Angle
T	Machined Laminated Phenolic Cage (Single Row Radial or A. C. Bearings)
DTD	Three Single Row Deep Groove Ball Bearings, Single Row Angular Contact Ball Bearings Or Single Row Tapered Roller Bearings Matched For Mounting In A Tandem Arrangement
P5	Dimensional And Running Accuracy To ISO Tolerance Class 5
