INA ZKLR1035-2Z
Price: 152.54 $
Specifications
| Brand | INA |
| Item Number | ZKLR1035-2Z INA |
| Manufacturer Part Number | 0053574110000 |
| EAN | 4054369574241 |
| Category | Angular Contact Ball Bearing Double Row |
| Inner (d) MM | 10 |
| Outer (D) MM | 28,14 |
| Width (B) MM | 17,5 |
| Inner (d) Inch | 0.3937 |
| Outer (D) Inch | 1.1079 |
| Width (B) Inch | 0.689 |
| Weight (kg) | 0.05 kg |
| Bore | C - Cylindrical Bore |
| Seal | ZZ/2Z - Steel Seal on Two Sides |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Split inner ring |
| Outside diameter bearing pot (D) mm | 28,14 |
| Radial Static Load Rating C0r (N) | 3900 |
| Width inner ring (B) mm | 16 |
| Radial Dynamic Load Rating Cr (N) | 7000 |
| Axial Static Load Rating C0a (N) | 2420 |
| Axial Dynamic Load Rating Ca (N) | 2430 |
| ECLASS number | 23-05-16-02 |
| ECLASS2 number | 23-05-16-02 |
| Medias description | Angular contact ball bearing units ZKLR..-2Z, double direction, for screw mounting, gap seals on both sides |
| 2Z | Gap Seals At Both Sides Of The Bearing |
