INA ZKLR0624-2Z
Price: 105.65 $
Specifications
| Brand | INA |
| Item Number | ZKLR0624-2Z INA |
| Manufacturer Part Number | 0041972320000 |
| EAN | 4054369574050 |
| Category | Angular Contact Ball Bearing Double Row |
| Inner (d) MM | 6 |
| Outer (D) MM | 20,5 |
| Width (B) MM | 13 |
| Inner (d) Inch | 0.2362 |
| Outer (D) Inch | 0.8071 |
| Width (B) Inch | 0.5118 |
| Weight (kg) | 0.023 kg |
| Bore | C - Cylindrical Bore |
| Seal | ZZ/2Z - Steel Seal on Two Sides |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Split inner ring |
| Outside diameter bearing pot (D) mm | 20,5 |
| Radial Static Load Rating C0r (N) | 2060 |
| Width inner ring (B) mm | 12 |
| Radial Dynamic Load Rating Cr (N) | 4100 |
| Axial Static Load Rating C0a (N) | 1520 |
| Axial Dynamic Load Rating Ca (N) | 1650 |
| ECLASS number | 23-05-16-02 |
| ECLASS2 number | 23-05-16-02 |
| Medias description | Angular contact ball bearing units ZKLR..-2Z, double direction, for screw mounting, gap seals on both sides |
| 2Z | Gap Seals At Both Sides Of The Bearing |
