INA ZKLN80130-2Z-XL

INA ZKLN80130-2Z-XL
INA ZKLN80130-2Z-XL rulman resim 1
INA ZKLN80130-2Z-XL rulman resim 2
INA ZKLN80130-2Z-XL rulman resim 3
INA ZKLN80130-2Z-XL rulman resim 4
INA ZKLN80130-2Z-XL rulman resim 5
Price: 3,654.50 $
Specifications
Brand INA
Item Number ZKLN80130-2Z-XL INA
Manufacturer Part Number 0015344080000
Also known as ZKLN80130-2Z
EAN 4054366006370
Category Angular Contact Thrust Ball Bearings, Double Direction
Weight and Dimensions
Inner (d) MM 80
Outer (D) MM 130
Width (B) MM 45
Weight (kg) 2.7 kg
Product Properties
Cage Type P - Plastic Molded Cage
Precision P4 Precision (Higher than P5)
Data from Schaeffler (medias)
Width (b) mm 45
Axial Static Load Rating C0a (N) 265000
Axial Dynamic Load Rating Ca (N) 100000
Limiting speed for grease lubrication (n G Grease) 3600
Thermally safe operating speed (n u03d1) 2700
ECLASS number 23-05-10-02
ECLASS2 number 23-05-10-02
Medias description Axial angular contact ball bearings ZKLN..-2Z, double direction, gap seals on both sides
Suffix description
2Z Gap Seals At Both Sides Of The Bearing
XL X-Life
