INA ZKLN1747-2RS-2AP-XL

Specifications

Brand	INA
Item Number	ZKLN1747-2RS-2AP-XL INA
Manufacturer Part Number	0015805400000
Also known as	ZKLN1747-2RS-2AP
EAN	4012802443271
Category	Angular Contact Thrust Ball Bearings, Double Direction

Weight and Dimensions

Inner (d) MM	17
Outer (D) MM	47
Width (B) MM	50
Weight (kg)	0.44 kg

Product Properties

Cage Type	P - Plastic Molded Cage
Precision	Matched Pair

Data from Schaeffler (medias)

Width (b) mm	50
Axial Static Load Rating C0a (N)	62000
Axial Dynamic Load Rating Ca (N)	33500
Limiting speed for grease lubrication (n G Grease)	7600
Thermally safe operating speed (n u03d1)	3300
ECLASS number	23-05-10-02
ECLASS2 number	23-05-10-02
Medias description	Axial angular contact ball bearings ZKLN..-2RS-2AP, matched pair, double direction, lip seals on both sides

Suffix description

2RS	Rubber Seals At Each Side Of The Bearing
2AP	Matched Pair (Twice The Number Of Bearings, Than Without 2AP)
XL	X-Life
