INA ZKLN100160-2Z-XL
Price: 5,975.20 $
Specifications
| Brand | INA |
| Item Number | ZKLN100160-2Z-XL INA |
| Manufacturer Part Number | 0015344240000 |
| Also known as |
ZKLN100160-2Z |
| EAN | 4012802589436 |
| Category | Angular Contact Thrust Ball Bearings, Double Direction |
| Inner (d) MM | 100 |
| Outer (D) MM | 160 |
| Width (B) MM | 55 |
| Inner (d) Inch | 3.937 |
| Outer (D) Inch | 6.2992 |
| Width (B) Inch | 2.1654 |
| Weight (kg) | 4.9 kg |
| Cage Type | P - Plastic Molded Cage |
| Precision | P4 Precision (Higher than P5) |
| Width (b) mm | 55 |
| Axial Static Load Rating C0a (N) | 435000 |
| Axial Dynamic Load Rating Ca (N) | 154000 |
| Limiting speed for grease lubrication (n G Grease) | 3300 |
| Thermally safe operating speed (n u03d1) | 2150 |
| ECLASS number | 23-05-10-02 |
| ECLASS2 number | 23-05-10-02 |
| Medias description | Axial angular contact ball bearings ZKLN..-2Z, double direction, gap seals on both sides |
| 2Z | Gap Seals At Both Sides Of The Bearing |
| XL | X-Life |
INA ZKLN100160-2Z
4.9 kg
100x160x55 mm
